3-Point Tractor
Attachments
42 - 52 PTO HP
1800 Series Heavy-Duty Dual Spindle Cutters
These Heavy-Duty Dual Spindle Cutters are designed for heavy-duty applications such as weeds, grass, and brush up to 3” diameter. These cutters are designed to work with 42 or 52 minimum hp tractors, and are available in 94” and 117” widths. The cutter uses dual spindles with two free-swinging blades each, which reduce the shock of impact when a stationary object is contacted. A slip clutch and dual shock couplers protect the gearboxes and drivelines from damage.
Standard equipment includes driveline shields and clutch shields. Front and rear chain discharge shields are available. Available in lift-type and pull-type models.
Available Colors:
Gray
, Orange
, Red
, Green
, Blue
Specs
Model:
| Product Family | 1800 Series |
| Product | 1808 |
| Description | 8' Heavy Duty Dual Spindle Cutter |
| RPM | 540 or 1000 |
| HP Required | 42 minimum PTO |
| Working Width | 96" |
| Transport Width | 98" |
| Weight | 1250 lbs |
| Cutting Height | 3-1/2" to 10" |
| Cutting Capacity | 3" |
| Deck Thickness | 10 GA |
| Side Bands | 8" |
| Skid Shoes | Replaceable |
| PTO Drive Shaft | Series 5 w/ slip clutch |
| Center Driveshaft | Shock Coupler Protected |
| Blade Holder | 1/2" Plate |
| Gearbox Rating | 125 HP |
| Outboard Gearbox Rating | 100 HP |
| Wheel Type | Laminated |
| Hub Type | Bearing |
| Hitch Type | Lift or Pull |
| Hitch | Cat 1 & 2 |
| Gearbox Warranty | 5 year limited |
| Guarding Options | Chains |
| Product Family | 1800 Series |
| Product | 1810 |
| Description | 10' Heavy Duty Dual Spindle Cutter |
| RPM | 540 or 1000 |
| HP Required | 52 minimum PTO |
| Working Width | 120" |
| Transport Width | 122" |
| Weight | 1480 lbs |
| Cutting Height | 3-1/2" to 10" |
| Cutting Capacity | 3" |
| Deck Thickness | 7 GA |
| Side Bands | 8" |
| Skid Shoes | Replaceable |
| PTO Drive Shaft | Series 5 w/ slip clutch |
| Center Driveshaft | Shock Coupler Protected |
| Blade Holder | 1/2" Plate |
| Gearbox Rating | 125 HP |
| Outboard Gearbox Rating | 100 HP |
| Wheel Type | Laminated |
| Hub Type | Bearing |
| Hitch Type | Lift or Pull |
| Hitch | Cat 1 & 2 |
| Gearbox Warranty | 5 year limited |
| Guarding Options | Chains |
