7300 Series Tube Frame Disc Harrow

These Tube Frame Disc Harrows are for medium-duty usage with notched discs which easily break up and redistribute cultivated topsoil. They will easily meet the needs of commercial landscapers, larger nurseries and gardens, as well as small farms. They are available in 60”, 72”, and 84” cutting widths and accept a Category I quick hitch. We offer three different models designed for tractors ranging from 30 to 50 hp.

View Specs

View Manual

Available Colors:

Gray

Specs

Model:

We've Got You Covered.

Find a Dealer near you to get started.

Dealer Locator

Become a Dealer

Product Family	7300 Series
Product	7316
Description	5' Tube Frame Disc Harrow
HP Required	30 - 40
Working Width	60"
# of Disc Blades	16
Disc Blade Size	16" or 18"
Disc Blade Spacing	7-1/2"
Weight (lbs)	650 lbs
Hitch	Cat 1
Notes	Unit has sealed bearings

Product Family	7300 Series
Product	7320
Description	6' Tube Frame Disc Harrow
HP Required	35 - 45
Working Width	72"
# of Disc Blades	20
Disc Blade Size	18"
Disc Blade Spacing	7-1/2"
Weight (lbs)	700 lbs
Hitch	Cat 1
Notes	Unit has sealed bearings

Product Family	7300 Series
Product	7324
Description	7' Tube Frame Disc Harrow
HP Required	40 - 50
Working Width	84"
# of Disc Blades	24
Disc Blade Size	18"
Disc Blade Spacing	7-1/2"
Weight (lbs)	750 lbs
Hitch	Cat 1
Notes	Unit has sealed bearings

Machine Width:	N/A
Machine Height:	N/A
Machine Length:	N/A
Wheelbase:	N/A
Operating Weight:	N/A
Tipping Load:	N/A
Operating Capacity:	N/A
Operating Capacity (50%):	N/A
Hydraulic Horsepower (Standard Flow):	N/A
Hydraulic Horsepower (High Flow):	N/A

3-Point Tractor

30 - 50 Engine HP
