2512 Series 12' Flex Wing Rotary Cutter

If you are looking for a Flex-Wing Rotary Cutter for your compact tractor, the IronCraft 2512 is the choice for you. With its smooth top deck and spring suspension, this flex-wing is designed to cut grass, weeds, and light brush up to 2” in material while only requiring a minimum PTO horsepower of 35 and one hydraulic outlet. With five different color choices you are able to match your cutter to your tractor.

Available Colors:

Gray
,
Orange
,
Red
,
Green
,
Blue

Specs

Model:

Product Family2512 Series
Product2512
Description12' Flex Wing Rotary Cutter
RPM540
HP Required35 minimum PTO (gear drive transmission)
Working Width144"
Overall Width151"
Overall Length158"
Tongue Weight759 lbs
Weight2630 lbs
Cutting Height1-1/2" to 12"
Cutting Capacityup to 2"
Deck Thickness10 GA
Deck Height11"
Side Bands3/16"
Hinge Rods1"
SuspensionSingle Spring
Skid ShoesReplaceable
PTO Drive ShaftASAE CAT 5 Constant Velocity
Wing Drive PTOASAE CAT 4
Driveline ProtectionSlip Clutch
Blade Holder3/16" formed plate w/ 3/4" x 2" blade bar
Gearbox Rating175 HP
Outboard Gearbox Rating75 HP
Blades1/2" x 3" with lift
Blade Overlap6"
Wheel TypeLaminated or Used Aircraft
Hitch TypeSwivel Clevis
Gearbox Warranty5 year limited
Safety Tow ChainStandard
Guarding OptionsSingle Row Chains Standardd
FPM15657
